Self-locking twisted shackle forged in grade 316L stainless steel.The pin is locked into one of the indentations.No risks of loose due to vibrations.Outstanding working and breaking loads.
Working load (kg) 480
WLL (kg) 220
Breaking load (kg) 1100
Weight (g) 16
A (mm) 26
B (mm) 10
C (mm) 5
D (mm) 10
D diameter (mm) 5
E (mm) 4
F (mm) 38
H (mm) 26
Other codes:
1223 with D 6mm
1224 with D 8mm
1225 with D 10mm
